OEM 32 Inch Curved Touch Screen J-Shape Curve Capacitive Touch Screen LCD Monitor For Game Cabinet
Products Description
The 32-inch curved touchscreen display, also known as the marquee display, is an eye-catching product. Equipped with an advanced LED backlight, its backlight life is more than 50,000 hours, providing users with a long-lasting and stable visual experience.
This curved touch screen has a high-definition resolution of 1920×1080, presenting a clear and delicate picture with more realistic details. The brightness reaches 300cd/㎡ and the contrast is as high as 1200:1, making the colors more vivid and the picture layering richer. The response time is only 6ms, which can present the picture in real-time to avoid the picture jamming phenomenon. In terms of color, it has 1.07B color and the color transition is natural and smooth.
The design of the 32-inch curved touch monitor provides users with the ultimate visual enjoyment. Its LED backlight source is not only energy-saving and environmentally friendly, but also can extend the service life of the product and ensure long-term stable operation. The backlight life of more than 50,000 hours allows users to not worry about the problem of frequent replacement of backlight tubes, and long-term use can also maintain stable brightness and color performance.
In terms of brightness and contrast, the 32-inch curved touchscreen display performs well. The high brightness of 300cd/㎡ makes the picture brighter and clearer, and can maintain good visibility even in a strong light environment. The contrast ratio of 1200:1 brings a more vivid picture effect, with obvious black-and-white contrast and fuller colors. The response time is 6ms, and the picture switching is smooth and natural, which greatly enhances the user’s visual experience. The display capability of 1.07B color enables the display to present more realistic and delicate color details, and the color transition is natural and smooth, allowing users to immerse themselves in it.
The 32-inch curved touch screen not only has excellent performance in picture performance but also in the viewing experience. Its horizontal and vertical viewing angles are both 178°, and users can enjoy clear and realistic display effects at almost any angle, whether watching movies, playing games, or doing office work, they can get the best visual experience.
Overall, the 32-inch curved touchscreen monitor provides users with a high-quality display device with excellent performance parameters and advanced technology. Whether in home entertainment, office work, or commercial applications, it can meet users’ needs for clear, vivid, and delicate pictures. The energy-saving and environmentally friendly LED backlight, long life, high-definition resolution, wide viewing angle, and rich color expression make this curved touchscreen display the only choice for users pursuing quality and experience.
Product Parameters
J-Type 32 Inch Curved Touch Screen Monitor | ||
LCD screen parameters | Model | JR32 |
Size | 32 Inch curved touchscreen | |
Resolution | 1920 × 1080 | |
Brightness | 300cd/㎡ | |
Contrast | 1200:1 | |
Display Ratio | 16:9 | |
Backlight | LED | |
Response Time | 6ms | |
Color | 1.07B | |
Viewing Angle | 178°(H)/178°(V) | |
Backlight Life | >=50,000H | |
Appearance | Capacitor + aluminum frame + sheet metal shell | |
Capacitive screen parameters | Touch Solution | Projected G+FF capacitive touch technology |
Response Time | <5ms | |
Number of touchpoints | Standard 10-point touch (can zoom in and out pictures, etc.) | |
Effective touch recognition | >1.5mm | |
Scanning frequency | 200HZ | |
Scanning accuracy | 4096 x 4096 | |
Communication method | Full-speed USB2.0, USB3.0 | |
Theoretical number of clicks | More than 50 million | |
Working current/voltage | 180Ma/DC+5V+/-5% | |
Anti-light interference | Normal when strong light such as sunlight, incandescent lamps, or fluorescent lamps changes | |
Touch data output method | Coordinate output | |
Surface hardness | Tempered glass, Mohs 7 explosion-proof glass | |
Operating system | compatibility Android system/Windows system | |
Driver | Driver-free, plug-and-play | |
External interface | HDMI input 1 | |
VGA input 1 | ||
3-M card | 12 years of industry experience | |
Countless motherboard tests | ||
USB/serial port-free switching | ||
Touch direction button adjustment | ||
USB/TTL/UUPD/RS232 | ||
Full tracking service, special program customization (remote/on-site) adaptation | ||
Light card | Computer control signal output | |
More than 300 lighting modes are available | ||
Can be connected to machine light strips and display light strips simultaneously | ||
Can connect 8 light strips, each with 1200 lamp beads |
